Making of Diamond Drill Bits

Manufacturing begins with CNC machining of the steel bit body, followed by precision placement and brazing of PDC cutters into engineered pockets. Blade configurations (typically 5 or 6 blades), hydraulic profiles, and connection threads such as API REG are designed based on the intended formation before final quality inspection and testing.

PDC bits use fixed polycrystalline diamond compact cutters that shear through rock via rotary motion, making them ideal for soft to medium formations. DTH (Down-The-Hole) hammer bits use tungsten carbide buttons and percussive impact energy delivered by a pneumatic hammer, making them better suited for hard, abrasive rock formations.

Yes. Infinity Tool MFG offers custom PDC bit manufacturing including non-standard diameters, blade counts, cutter placement, and connection types. Our in-house engineering and drafting team works directly with customers to develop proprietary bit configurations for oil & gas, mining, geothermal, water well, and HDD applications.

PDC diamond drill bits are engineered to handle soft, medium, and hard rock formations depending on cutter density, blade count, and profile design. Our PDC bits, reamers, and hole openers are available in configurations optimized for soft formations through hard, abrasive rock, ensuring efficient penetration across a wide range of drilling conditions.

In-stock PDC bits and rock tools typically ship within 2 working days. Custom-manufactured bits require additional lead time depending on complexity and specifications. Expedited or urgent shipment coordination is available upon request by contacting our sales team directly.

Our PDC diamond drill bits are manufactured with industry-standard API REG PIN connections, including 4-1/2" and 7-5/8" sizes, ensuring compatibility with standard drilling equipment and drill strings used across oil & gas, water well, geothermal, and construction drilling rigs.
